Series Number
|
1N400x Series
|
|
Description
|
Silicon Rectifier 1.0A DO-41 Axial Leaded
|
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
–
|
Product Characteristics
| Max Reverse DC Voltage | 50 ~ 1000V |
| Max Forward Current | 1.0A |
| Max Forward Voltage | 1.1V |
| Peak Forward Surge Current | 30.0A |
| Operating Temperature | -55 ~ 150 °C |
| Package / Case | DO-41 |
| Applications | General Purpose |
| Mounting Type | Through Hole |
| Max Reverse Current @ 25 °C | 5.0 μA |
| Thermal Resistance | 50.0 °C/W |
| Junction Capacitance | 15pF |
| Storage Temperature | -55 ~ 150 °C |
| Leaded Type | Axial Leaded |
| Features | High Surge Capability |
| Maximum Reverse Recovery Time | 200 ns |
| Series | 1N400x Series |
| Packaging | Tape and Reel |
| Part Status | Active |
