Series Number
|
SIM06-32
|
|
Description
|
Ferrite Chip Bead High Current Type SMD
|
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
–
|
Product Characteristics
| Impedance | 30 ~ 600Ω |
| Tolerance | +/-25% |
| DC Resistance (Max.) | 0.04 ~ 0.2Ω |
| Rated Current (Max.) | 1000 ~ 3000mA |
| Operating Temperature | -40 ~ +125 °C |
| Package / Case | 1206 |
| Applications | General Purpose |
| Mounting Type | Surface Mount |
| Size / Dimension | 3.2×1.6mm |
| Thickness (Max) | – |
| Test Frequency | 100MHz |
| Rating | High Current Type |
| Features | Excellent Solderability and Heat Resistance |
| Reel Size | 7 inches |
| Qty Per Reel (pcs) | 4,000 |
| Series | SIM06-32 |
| Packaging | Tape and Reel |
| Part Status | Active |
