Series Number
|
SIM01-C11
|
|
Description
|
SMD Ceramic Chip Inductor
High Frequency Type |
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
Small Size and Low Profile
|
Product Characteristics
| Inductance(nH) | 0.3 ~ 39 nH |
| Tolerance | +/-0.1~5%, +/-2%, +/-3%,+/- 5%, +/- 10% |
| Q Min. | 4~5 |
| Rated Current (Max.) | 120 ~850mA |
| Operating Temperature | -55~ +125 degC |
| Package / Case | 01: 0201/02: 0402/03:0603 |
| Feature | High Frequency Application Range up to 10GHz |
| SRF(MHz) Min. | 1,500~10,000 |
| Size / Dimension | 01/02/03 |
| DCR (Ω) Max. | 0.07 mm~2.4mm |
| Test Frequency | 100 |
| Rated Current (mA) Max. | 120~850 mA |
| Applications | RF and Wireless Communication, Information Technology Equipment, Radar Detectors, Automotive Electronics. |
| Reel Size | 0202/0402/0603 |
| Qty Per Reel (pcs) | 4,000~15,000 |
| Series | SIM01-C11 |
| Packaging | Tape and Reel |
| Part Status | Active |
