Series Number
|
PIM-0502BMA2
|
|
Description
|
0502B SMD Molded Power Inductor – High Current, Low DCR
|
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
AEC-Q200 Compliant
|
Product Characteristics
| Inductance | 0.15 ~ 1.5uH |
| Tolerance | +/-20% |
| DC Resistance Typical | 4 ~ 16.2mohm |
| DC Resistance Max. | 4.6 ~ 18.7mohm |
| Operating Temperature | -55 ~ 155 degC (see datasheet) |
| Package / Case | 0502B |
| Applications | Automotive, AECQ200 |
| Mounting Type | Surface Mount |
| Saturation Current | 13.3 ~ 30A |
| Rated Current | see datasheet |
| Test Frequency | 100KHz |
| Height | 1.9mm +/-0.2 |
| Size | 6mm x 5.7mm |
| Features | High Efficiency, Soft Saturation |
| Ratings | – |
| Series |
PIM-0502BMA2
|
| Packaging | Tape and Reel |
| Part Status | Active |
