Series Number
|
PIM-0402MA1
|
|
Description
|
MOLDED INDUCTOR, 4.5X4.0X1.8mm AECQ
|
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
Product Characteristics
| Inductance | 0.1 ~ 22μH |
| Tolerance | ±20~30% |
| DC Resistance Typical | 3.2 ~ 470mΩ |
| DC Resistance Max. | 4.0 ~ 500mΩ |
| Operating Temperature | -55 ~ 125 ˚C (including self-temperature rise) |
| Package / Case | 0402 |
| Applications | Note PC Power System, incl. IMVP-6, DC/DC Converter |
| Mounting Type | Surface Mount |
| Saturation Current | 1.4 ~ 35A |
| Rated Current | 1.2 ~ 14A |
| Features | High Current, Low DCR, High Efficiency |
| Packaging | Tape and Reel |
| Part Status | Active |
