Series Number
|
PIM-0302MA1
|
|
Description
|
0302 SMD Molded Power Inductor – High Current
|
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
AEC-Q200 Compliant
|
Product Characteristics
| Inductance | 0.10 ~ 10uH |
| Tolerance | +/-20%, +/-30% (see datasheet) |
| DC Resistance Typical | 6.6 ~ 366mohm |
| DC Resistance Max. | 9 ~ 422mohm |
| Operating Temperature | -55 ~ 125 degC (see datasheet) |
| Package / Case | 0302 |
| Applications | Automotive, AECQ200 |
| Mounting Type | Surface Mount |
| Saturation Current | 1.6 ~ 14A |
| Rated Current | 1.4 ~ 10.5A |
| Test Frequency | 100KHz |
| Height | 1.8mm +/-0.2 |
| Size | 3.5mm x 3.2mm |
| Features | Low DCR, High Efficiency |
| Ratings | – |
| Series | PIM-0302MA1 |
| Packaging | Tape and Reel |
| Part Status | Active |
