Series Number
|
PE5P
|
|
Description
|
Conductive Polymer Capacitor – Radial 5000 hours
|
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
–
|
Product Characteristics
Product Characteristics
| Capacitance | 270~1500uF |
| Tolerance | +/-10%, +/-20% typ. (options available) |
| Voltage – Rated | 6.3~16VDC |
| Max ESR @100kHz | 8 ~ 14 mohm |
| Operating Temperature | -55 ~ 105degC |
| Package / Case | Radial Can |
| Applications | General Purpose |
| Mounting Type | Through Hole |
| Dissipation Factor (Tangent) | 0.1 |
| Leakage Current Max. | 705 ~ 3200 uA |
| Ripple Current @100kHz | 3500 ~ 6100 Arms |
| Size / Dimension | 6.3(dia.)x6.0mm (Options) |
| Leaded Type | Radial Leaded |
| Features | Low ESR, High Ripple Current |
| Load Life | 5000 Hours @ 105degC |
| Series | PE5P |
| Packaging | Bulk |
| Part Status | Active |
