Series Number
|
SLL
|
|
Description
|
SMD Aluminum Electrolytic Capacitors – Low Leakage, 2000 hours at 85°C
|
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
–
|
Product Characteristics
| Capacitance | 1 ~ 100uF |
| Tolerance | 20% |
| Voltage – Rated | 6.3, 10, 16, 25, 35, 50V |
| Lifetime @ Temp. | 2000 Hours @ 85 °C |
| Operating Temperature | -40 ~ 85 °C |
| Package / Case | Radial Can |
| Applications | General Purpose |
| Mounting Type | Surface Mount |
| Size / Dimension | Diameter: 4, 5, 6.3mm |
| Height – Seated (Max) | (See specsheet) |
| Thickness (Max) | (See specsheet) |
| Lead Spacing | (See specsheet) |
| Case Size DxL (mm) | 4×5.4, 5×5.4, 6.3×5.4 |
| Features | Low Leakage |
| Load Life | 2000 Hours @ 85 °C |
| Series | SLL |
| Packaging | Tape and Reel |
| Part Status | Active |
